p. 5 - Manual FA01719-EN - 03/2022 - © CAME S.p.A. - Translated original instructions
KEY
This symbol shows which parts to read carefully.
⚠
This symbol shows which parts describe safety issues
☞
This symbol shows which parts to tell users about.
The measurements, unless otherwise stated, are in millimeters.
DESCRIPTION
Operator featuring a control board, movement-control and obstruction-detecting device, plus, mechanical limit-
switches for sliding gates of up to 1000 kg and 20 m in length.
INTENDED USE
The operator is designed to power sliding gates in residential and apartment block settings.
 Do not install of use this device in any way, except as specified in this manual.
LIMITS TO USE
Type BXV04AGF
BXV06AGF
BXV06RGF
BXV10AGF
BXV10RGF
Maximum gate-leaf length (m) 14 18 20
Maximum gate-leaf weight (kg) 400 600 1000
Pinion module 4 4 4
TECHNICAL DATA
Type BXV04AGF BXV06AGF BXV10AGF BXV06RGF BXV10RGF
Protection rating (IP) 44 44 44 44 44
Power supply (V - 50/60 Hz) 230 AC 230 AC 230 AC 120 AC 120 AC
Input voltage motor (V) 24 DC 24 DC 24 DC 24 DC 24 DC
Stand-by consumption (W) 5.5 5.5 5.5 5.5 5.5
Stand-by consumption with the
RGP1 (W) module
0.5 0.5 0.5 0.5 0.5
Maximum power (W) 240 240 360 240 360
Duty cycle
HEAVY-DUTY
SERVICE
INTENSIVE
SERVICE
INTENSIVE
SERVICE
INTENSIVE
SERVICE
INTENSIVE
SERVICE
Operating temperature (°C) -20 to +55 -20 to +55 -20 to +55 -20 to +55 -20 to +55
Thrust (N) 250 330 450 330 450
Max. maneuvering speed 22 20 20 20 20
Apparatus class I I I I I
Weight (Kg) 10 11.5 12 11.5 12
Storage temperature (°C)* -20 ÷ +70 -20 ÷ +70 -20 ÷ +70 -20 ÷ +70 -20 ÷ +70
Average life (cycles)** 150000 150000 150000 150000 150000
(*) Before installing the product, keep it at room temperature where it has previously been stored or
transported at a very high or very low temperature.
(**) The average product life specified should be understood purely as an indicative estimate. It applies to
normal usage conditions and where the product has been installed and maintained in compliance with the
instructions provided in the CAME technical manual. The average product life is also affected, including
significantly, by other variables such as, but not limited to, climatic and environmental conditions. The
average product life should not be confused with the product warranty.
