The data and information shown in this manual may be changed by CAME cancelli automatici s.p.a. at any time without prior warning.
ENGLISH
1
4
3
Hinge
Gate stop
D = 240 mm. max
Opened to 90°
Opening
angle
ABC
90°
140÷205 0÷50 430
140÷195 75÷100 430
140÷185 125÷150 400
140÷175 175÷200 400
110°
180÷210 0 430
200÷205 50 430
194 218
245
2
4.4 Dimensions and basic measurements
4.3 Description of parts
A1824
1) Operator
2) Pillar bracket
3) Articulated transmission arm
4) Gate bracket
