The data and information shown in this manual may be changed by CAME cancelli automatici s.p.a. at any time without prior warning.
2
ENGLISH
#
#
4.1 Operator
4 Description
2.1 Intended use
1 Legend of symbols
This symbol tells you to read the section with particular care.
This symbol tells you that the sections concern safety issues.
This symbol tells you what to say to the end-users.
2 Destination and conditions of use
The F7024N operator is designed to power residential and condominium swing gates with gate leaves weighing up
to 300 kg. Do not install or use unless as otherwise shown in this manual.
3 Reference Standards
“IMPORTANT INSTALLATION, SAFETY INSTRUCTIONS”
“CAUTION: IMPROPER INSTALLATION MAY CAUSE SERIOUS DAMAGE, FOLLOW ALL INSTALLATION INSTRUCTIONS CAREFULLY”
“THIS MANUAL IS ONLY FOR PROFESSIONAL OR QUALIFIED INSTALLERS”
2.2 Conditions of use
This product is engineered and manufactured by CAME CANCELLI AUTOMATICI S.p.A. and complies with current safety regu-
lations. Guaranteed 24 months if not tampered with.
External operator with articulated arm for swing gates.
Self-locking 24V D.C. gearmotor.
4.2 Technical features
Control board power supply: 230V a.c. 50/60Hz
Motor power supply: 24V d.c.
Max draw: 11A
Power: 140W
Max couple: 180Nm
Opening time (90°): fron 16 to 45s
Duty Cycle: Intensive use
Protection Rating: IP54
Weight: 28 kg
Insulation class:
The company: CAME cancelli automatici is ISO 9001:2000 quality certified; is has also obtained the ISO 14001 environmen-
tal safeguarding certification. CAME engineers and manufactures all of its products in Italy.
This product complies with the following standards: EN 12978, UNI EN 954-1, CEI EN 60335-1, UNI EN 12453.
Gate leaf width 1 m 1,5 m 2 m 2,3 m max
Gate leaf weight 300 kg max 250 kg 215 kg 200 kg
Opening 110° max
