1.0 05/2012
© CAME Cancelli Automatici S.p.A. - The data and information in this manual may be updated at any time by Came Cancelli Automatici S.p.A. which is under no obligation to notify said updates.
ENGLISH
Fence off the site and follow all safety
prescriptions for mechanical moving
vehicles. Danger Tilting
- Hitch three steel cables with hooks, on the end that can hoist
at least 250 kg, to the eyelets on the head of the central element.
- Pull the cable taut with a mechanical arm and then hoist the
central element and place it above the base.
- Slowly lower the central element, and centre the holes at the
base until it is resting.
- Remove all harnesses.
- Position and lock the 10 issued bolts into place at the base of
the central element.
The automatic cash-register is
supplied in three disassembled parts:
• the base
• the central element
• the closing element
Base
Closing element
Central element
9.2 Mounting the automatic cash register
