ENGLISH
- Place the upper element atop the central one and fasten it by tightening
the nine issued bolts.
- Inside the upper compartment, on the left side, connect the
power supply cable coming from the base into its corresponding
terminal.
- Plug the LED connector into the upper element on the left
side of the cash register.
9.3 ETHERNET power supply and connection
