Pag. 14 - FA01289M4A - 12/2018 © Came S.p.A.
ENGLISH
General Precautions
• Important safety instructions. READ CAREFULLY
• Installing, programming, commissioning and maintenance
must only be done by qualified, expert sta and in full compli-
ance with the applicable law.
• Wear antistatic protective clothing and footwear when work-
ing on the control board.
• Keep these precautions.
• Always cut o the mains power when doing cleaning and
maintenance jobs.
• This product must only be used for the purpose for which it
was designed. Any other use is dangerous.
• The manufacturer declines all liability for any damage as a
result of improper, incorrect or unreasonable use.
Description
RGSM001
(GSM Master with 868 MHz radio transmitter)
Module for remote management of one or more CAME opera-
tors, via CAMEConnect; featuring two digital inputs, two N. O.
relay outputs, 868 MHz radio transmitter, 485 interface and GSM
board. This devices can be used as a master module to manage
up to five slave modules associated with it, which in turn are able
to manage one or several operators.
The device is equipped with an external wire antenna
which must not be removed.
RGSM001S
(GSM Master without 868 MHz radio transmitter)
Module for remotely controlling and managing up to three CAME
operators via CAMEConnect, fitted with two digital inputs, two
relay outputs, 485 interface and GSM card.
Do not install radio devices less than four meters apart.
Place the antenna as high as possible from the ground,
away from any metal or reinforced concrete structures.
Description of parts
❶ GSM LED (blue), ❷ OUT1 LED (red), ❸ OUT2 LED (red),
❹ LED POWER (green), ❺ LED CONNECT (red).
❻ P1 button for resetting or rebooting the module.
Press and hold for 10 seconds to restore the module to fac-
tory settings (reset); press and hold for 3 seconds and then
release to restart the module.
If the module that is reset to factory settings has already
been registered and configured from a CAME Connect ac-
