1.2
04/2010
9 © CAME cancelli automatici s.p.a. -
The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH
1) Keep the CH1 button on the electronic card pressed. The LED fl ashes.
2) Press the transmitter button you wish to memorise. The LED will stay on to show memorisation has been successful.
LED flashing
LE
D on
11.4 - MEMORISATION
CH1 = Channel for direct command to a function of the the gearmotor’s card, (“open only / “open-close-invert” or “open-stop-close-stop”
command, depending on the choice made on DIP switches 2 and 3).
CH2 = Channel for direct command an accessory device connected to B1-B2.
3) Repeat the points 1 and 2 procedures for the “CH2” button associating this to another button on the transmitter.
