p. 9 - Manual FA01082-EN - 02/2018 - © CAME S.p.A. - Translation of the original instructions
10_E /
10_E3 contacts rated for 24V - 25W max.
10_5 24V - 3W max.
Courtesy light. - Outdoor light for additional lighting
in the drive way.
See function [Court. Time] function in the
[SETTIMES] menu.
Movement flashing light. - It flashes when the
gate is opening and closing.
- ALTERNATIVELY -
Cycle light. - Outdoor light for additional lighting
in the driveway:
See function [Light E] function in the
[FUNCTIONS].
Gate open warning light. - It
warns that the gate is open and
switches o when the gate is
closed.
Warning and lighting devices
Connecting ENCODER-fitted gearmotors
= Green
M1 - Gearmotor with
delayed opening.
M1 - Gearmotor with
delayed opening.
