Cameron LEFM 200 - Acoustic Data Quality

IB0147 Rev. 08 LEFM 200 Modbus User Manual
Section 4 Page 26 December 2010
4.2 Acoustic Data Quality
Percent of data collected that is rejected
due to signal to noise ratio, cross-correlation tests, or statistics
Output Variable
Input Register
Variable
Definition
Address Units Notes
Integer 16 % Path 1
Integer 17 % Path 2
Integer 18 % Path 3
Integer 19 % Path 4
Integer 516 % Path 5
Integer 517 % Path 6
Integer 518 % Path 7
Integer 519 % Path 8
Measured signal to noise ratio (Average)
Output Variable
Input Register
Variable
Definition
Address Units Notes
Integer 24 N/A Path 1 Avg
Integer 25 N/A Path 2 Avg
Integer 26 N/A Path 3 Avg
Integer 27 N/A Path 4 Avg
Integer 524 N/A Path 5 Avg
Integer 525 N/A Path 6 Avg
Integer 526 N/A Path 7 Avg
Integer 527 N/A Path 8 Avg
