4.8 Meter and Path Status Data
Status Registers
Output Variable
Input Register
Variable
Definition
Address Units Notes
Board Status Integer 72 0 = Normal, 1 = Needs Setup,
2 = Board Failed Checksum, 3 = No GSS
Path Status
(0 = normal, 1 = path failing due to rejects, 6 = path is failing a speed of sound test)
Output Variable
Input Register
Variable
Definition
Address Units Notes
PathStatus1 Integer 74 N/A Path 1
PathStatus2 Integer 75 N/A Path 2
PathStatus3 Integer 76 N/A Path 3
PathStatus4 Integer 77 N/A Path 4
PathStatus5 Integer 574 N/A Path 5
PathStatus6 Integer 575 N/A Path 6
PathStatus7 Integer 576 N/A Path 7
PathStatus8 Integer 577 N/A Path 8
