IB0147 Rev. 08 LEFM 200 Modbus User Manual
Section 4 Page 30 December 2010
Analog Inputs
Output Variable
Input Register
Variable
Definition
Address Units Notes
AnalogInput1 Float 82 Volts
AnalogInput2 Float 84 Volts
AnalogInput3 Float 86 Volts
AnalogInput4 Float 88 Volts
Analog Input Status Integer 210 wxyz
w = A/I 1
x = A/I 2
y = A/I 3
z = A/I 4
0 = Normal
1 = Fail Low
2 = Fail High
4.5 Setup File Information
Setup File Information
Output Variable
Input Register
Variable
Definition
Address Units Notes
Number of times setup
has been modified
Integer 149
CheckSum of setup file Integer 148
