IB0147 Rev. 08 LEFM 200 Modbus User Manual
Section 4 Page 28 December 2010
Path Gain Data
Output Variable
Input Register
Variable
Definition
Address Units Notes
Path Gain 1 (direct) Float 212 dB Average Up & DN
Path Gain 2 (direct) Float 214 dB Average Up & DN
Path Gain 3 (direct) Float 216 dB Average Up & DN
Path Gain 4 (direct) Float 218 dB Average Up & DN
Path Gain 5 (direct) Float 712 dB Average Up & DN
Path Gain 6 (direct) Float 714 dB Average Up & DN
Path Gain 7 (direct) Float 716 dB Average Up & DN
Path Gain 8 (direct) Float 718 dB Average Up & DN
Path Gain 1 (echo) Float 220 dB Average Up & DN
Path Gain 2 (echo) Float 222 dB Average Up & DN
Path Gain 3 (echo) Float 224 dB Average Up & DN
Path Gain 4 (echo) Float 226 dB Average Up & DN
Path Gain 5 (echo) Float 720 dB Average Up & DN
Path Gain 6 (echo) Float 722 dB Average Up & DN
Path Gain 7 (echo) Float 724 dB Average Up & DN
Path Gain 8 (echo) Float 726 dB Average Up & DN
