Table 6-1: Connector and compatible sensors
Connector
Compatible sensors
(one sensor per connector)
1
RAIN TE525 Rain Gage
WIND 05103 wind speed and temperature sensor
TEMP/RH
107 temperature probe, 108 temperature probe, HMP60
temperature and relative humidity sensor, or EE181
SOLAR RADIATION
CS305-ET pyranometer, CS100 barometer
2
, CS106 barometer
2
,
GPS16X-HVS GPS Receiver with Integrated Antenna
1
Choose the -C cable termination option (except for the CS305-ET, barometers, and GPS16X-HVS).
2
The barometers use the CS110 to Barometric Pressure Sensor Cable to connect to the CS110, and must be housed
in a separate enclosure.
RAIN connector
Example CRBasic instructions for measuring the TE525:
PulseCount(rain_fall,1,2,2,0,0.01,0) 'TE525 tipping bucket 0.01 inches per tip
WIND connector
Example CRBasic instructions for measuring the 01503:
PulseCount (wind_speed,1,1 ,1,1,0.2192,0) 'Wind Speed.
BrHalf (wind_dir,1,mV2500,4,Vx2,1,2500,False,450,_60Hz,355,0) 'Wind Direction.
TEMP/RH connector
Example CRBasic instructions for measuring the EE181:
SW12(1) 'Turn on switched 12V
Delay(0,2,Sec) '2-second delay
'EE181 Temperature & Relative Humidity Sensor measurements AirTC and RH:
VoltSe(AirTemp,1,mV2500,2,0,0,_60Hz,0.1,-40)
VoltSe(RH,1,mV2500,1,0,0,_60Hz,0.1,0)
SW12(0) 'Turn off switched 12V
SOLAR RADIATION connector
Example CRBasic instruction for measuring the CS305 pyranometer:
'Measure the CS305
VoltDiff (solar_rad,1,mV7_5,3,True,450,_60Hz,200,0)
CS110 Electric Field Meter 11
