Campbell CS110 - Page 43

RS-232 connector
The CS110CBL1-L includes a military connector that attaches to the CS110 RS-232 connector and a
9-pin connector that attaches to FC100 fiber optic converter.
Table A-7: RS-232 connector pin number and description
Pin number Description
1 Data terminal ready
2 Transmit
3 Receive
4 empty
5 Power ground
6 Tied to pin 1
7 Clear to send
8 Request to send
9 Ring
