REFIT THE DOOR
1. Hold the door rmly (g. 4.10).
2. Insert the hinge tongues into the slots, making sure that the groove drops into place
as shown in the gure 4.11.
3. Open the door to its full extent.
4. Fully close the levers “A” on the left and right hinges, as shown in the gure 4.12.
5. Close the door and check that it is properly in place.
A
Fig. 4.11
Fig. 4.10
Fig. 4.12
