113
Specifications
Flash Recycling
AF-assist Beam
Radio Transmission Wireless Function (600EX-RT only)
Optical Transmission Wireless Function
Recycling time: Normal flash: approx. 0.1 - 5.5 sec.,
Quick Flash: approx. 0.1 - 3.3 sec.
*When using AA/LR6 alkaline batteries
Flash-ready lamp display: Lit in red: normal flash available
Lit in green: Quick Flash available
Compatible AF system: 1 - 61 AF points (28 mm or longer focal length)
*During viewfinder shooting, and Quick Mode during Live
View shooting or movie shooting supported
Effective range: At center: approx. 0.6 - 10 m / 2.0 - 32.8 ft., periphery:
approx. 0.6 - 5 m / 2.0 - 16.4 ft.
Frequency: 2405 - 2475 MHz
Modulation system: Primary modulation: OQPSK, secondary modulation: DS-SS
Wireless settings: Master/slave
Channel: Auto, Ch. 1 - 15
Wireless radio ID: 0000 - 9999
Slave unit control: Up to 5 groups (A/B/C/D/E), up to 15 units
Transmission distance: Approx. 30 m / 98.4 ft.
*When there are no obstacles or obstructions between the
master unit and slave unit, and no radio interference with
other devices
*The transmission distance may be shorter depending on
the relative positions of the units, surrounding environment
and weather conditions
Flash ratio control: 1:8 - 1:1 - 8:1, power 1/2-stop increments
Slave flash battery check: <Q> icon lights on the master unit’s LCD panel, slave unit’s
AF-assist beam emitter blinks, flash-ready lamp lights
Linked shooting: Provided
Connection method: Optical pulse
Wireless settings: Master/slave
Channel: Ch. 1 - 4
Slave unit control: Up to 3 groups (A/B/C)
Transmission distance: Indoors: approx. 0.7 - 15 m / 2.3 - 49.2 ft.,
outdoors: approx. 0.7 - 10 m / 2.3 - 32.8 ft. (at the front)
±40° horizontally and ±30° vertically, facing the master unit
Flash ratio control: 1:8 - 1:1 - 8:1, power 1/2-stop increments
Slave flash battery display: Slave unit’s AF-assist beam emitter blinks, flash-ready lamp
lights
