Canon imagePRESS Server M10 - Replacing Parts; Removing the HDD Assembly

6. Carefully lift the HDD assembly to release its lower edge from the mounting posts in the chassis, and then remove
the HDD assembly from the chassis.
1
2
Figure 27: Removing the HDD assembly
No. Name
1 Screw (1 of 2)
2 HDD assembly
3. REPLACING PARTS
41
