Canon imagePROGRAF iPF6400 Basic Guide

→User's Guide (HTML)
1
Press the Load button.
2 Press ▲ or ▼ to select Roll Paper, and then press the OK button.
Note
• If any paper has been advanced that will not be used, a message is shown requesting you to remove it.
Press ▲ or ▼ to select "Yes", and then press the OK button. Remove the paper and go to the next step.
3
Open the Roll Feed Unit Cover.
4
Holding the Roll Holder flange (a), load the Roll
Holder shaft into the guide grooves (b) on both
sides of the Roll Holder Slot. At this time, load the
shaft so that the color of the Roll Holder shaft (c)
matches the color of the guide groove.
Caution
• Do not release the flanges until you load the holder fully in the Roll Holder Slot. Rolls are heavy, and dropping
a roll may cause injury.
• Be careful not to pinch your fingers between the guide grooves (b) and the Roll Holder shaft (c) when loading
rolls.
Important
• Do not force the Roll Holder into the printer with the right and left ends reversed. Otherwise, it may damage
the printer or Roll Holder.
Loading Rolls in the Printer iPF6400
Basic Guide
Handling Paper Handling rolls
12

Canon imagePROGRAF iPF6400 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Grey, Magenta, Matte black, Photo cyan, Photo grey, Photo magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO
Maximum print size	-
Maximum roll length	18 m
ISO A-series sizes (A0...A9)	A1, A2
ISO B-series sizes (B0...B9)	B2
Internal memory	384 MB
Sound pressure level (printing)	47 dB
Power supply	100 W
Power consumption (off)	5 W
Power consumption (standby)	6 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
USB port	No
USB 2.0 ports quantity	0
