Canon imagePROGRAF iPF6400 Basic Guide

7
Close the Roll Feed Unit Cover.
Important
• Cut the edge of the roll using the Paper Cutting function if the edge is creased or soiled. (See "Specifying the
Cutting Method for Rolls.") →User's Guide
Note
• Adjusting the printhead alignment with the type of paper to be used in printing may enhance printing quality.
(See "Automatic Adjustment to Straighten Lines and Colors.") →P.85
Removing the Roll from the Printer
Removing the Roll from the Printer
Remove rolls from the printer as follows.
Important
• Once a roll has been advanced, do not pull the paper out by force. This will prevent further feeding, and the printer will
be unable to keep track of the amount of roll paper left.
If you accidentally pull out paper, follow these steps to remove the roll, and open the paper feed slot.
Note
• If you need to cut the roll, see "Specifying the Cutting Method for Rolls." →User's Guide
1
On the Tab Selection screen of the Control Panel, press ◀ or
▶ to select the
(Paper tab) .
Note
• If the Tab Selection screen is not displayed, press the Menu button.
2 Press the OK button.
The Paper Menu is displayed.
3 Press ▲ or ▼ to select Eject Paper, and then press the OK button.
Removing the Roll from the Printer iPF6400
Basic Guide
Handling Paper Handling rolls
14

Canon imagePROGRAF iPF6400 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Grey, Magenta, Matte black, Photo cyan, Photo grey, Photo magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO
Maximum print size	-
Maximum roll length	18 m
ISO A-series sizes (A0...A9)	A1, A2
ISO B-series sizes (B0...B9)	B2
Internal memory	384 MB
Sound pressure level (printing)	47 dB
Power supply	100 W
Power consumption (off)	5 W
Power consumption (standby)	6 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
USB port	No
USB 2.0 ports quantity	0
