Canon imagePROGRAF iPF6400 Basic Guide

3
With the Roll Holder resting horizontally and the
edge of the roll paper facing forward as shown, in-
sert the roll in the Roll Holder from the left. Insert
the roll firmly until it touches the flange (a) of the
Roll Holder, leaving no gap.
Important
• Always have the Roll Holder resting horizontally when loading rolls. Attempting to load rolls with the Roll Hold-
er upright may damage the Roll Holder.
4
Insert the Holder Stopper from the left in the Roll Hold-
er as shown. Push it firmly in until the flange (a) of the
Holder Stopper touches the roll.
Attach the appropriate Holder Stopper for the size of
the paper core.
Loading Rolls in the Printer
Loading Rolls in the Printer
Follow these steps to load rolls in the printer.
Important
• Always load rolls when the printer is on. If the printer is off when you load a roll, the paper may not be advanced
correctly when you turn the printer on.
• Before loading a roll, confirm whether the inside of the Top Cover or the Ejection Guide is soiled. If soiled, we recom-
mend cleaning in advance. (See "Cleaning Inside the Top Cover.") →P.46
iPF6400 Loading Rolls in the Printer
Basic Guide
Handling Paper Handling rolls
11

Canon imagePROGRAF iPF6400 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Grey, Magenta, Matte black, Photo cyan, Photo grey, Photo magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO
Maximum print size	-
Maximum roll length	18 m
ISO A-series sizes (A0...A9)	A1, A2
ISO B-series sizes (B0...B9)	B2
Internal memory	384 MB
Sound pressure level (printing)	47 dB
Power supply	100 W
Power consumption (off)	5 W
Power consumption (standby)	6 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
USB port	No
USB 2.0 ports quantity	0
