Canon imagePROGRAF iPF815 - Page 205

Chapter 4
4-55
4. Upper cover stay shaft hole [1]/The gear shaft of the upper cover stay gear [2]/Upper cover stay shaft end [3]/The gear tooth face of upper cover stay [4]
F-4-117
[1]
[2]
[4]
[3]
