Chapter 6
6-3
T-6-2
T-6-3
42 /CBE2 OUT Bus command and byte enable signal
43 GND - GND
44 /FRAME IN/OUT Cycle frame signal
45 /IRDY IN/OUT Initiator ready signal
46 /TRDY IN/OUT Target ready signal
47 /DEVSEL IN/OUT Device select signal
48 GND - GND
49 /STOP IN/OUT Stop signal
50 /LOCK IN/OUT Lock signal
51 /PERP IN/OUT Parity error signal
52 /SERR IN/OUT System error signal
53 PAR IN/OUT Parity signal
54 /CBE1 IN/OUT Bus command and byte enable signal
55 GND - GND
56 GND - GND
57 AD15 IN/OUT Address and data signal
58 AD14 IN/OUT Address and data signal
59 AD13 IN/OUT Address and data signal
60 AD12 IN/OUT Address and data signal
61 GND - GND
62 AD11 IN/OUT Address and data signal
63 AD10 IN/OUT Address and data signal
64 AD9 IN/OUT Address and data signal
65 AD8 IN/OUT Address and data signal
66 /CBE0 IN/OUT Bus command and byte enable signal
67 GND - GND
68 AD7 IN/OUT Address and data signal
69 AD6 IN/OUT Address and data signal
70 AD5 IN/OUT Address and data signal
71 AD4 IN/OUT Address and data signal
72 GND - GND
73 AD3 IN/OUT Address and data signal
74 AD2 IN/OUT Address and data signal
75 AD1 IN/OUT Address and data signal
76 AD0 IN/OUT Address and data signal
77 GND - GND
78 HDD_LED - N.C.
79 +5V OUT Power supply(+5V)
80 +5V OUT Power supply(+5V)
81 +5V OUT Power supply(+5V)
82 +3.3V OUT Power supply(+3.3V)
83 +3.3V OUT Power supply(+3.3V)
84 +3.3V OUT Power supply(+3.3V)
85 GND - GND
86 GND - GND
87 GND - GND
88 GND - GND
J1201
Pin Number Signal name IN/OUT Function
1 AGND2 - GND
2 TXP OUT Transmission Data
3 TXN OUT Transmission Data
4 AGND2 - GND
5 RXN IN Receive Data
6 RXP IN Receive Data
7 AGND2 - GND
J1202
Pin Number Signal name IN/OUT Function
1 HDD_LED IN Access signal
2 +5V IN Power supply(+5V)
J1101
Pin Number Signal name IN/OUT Function
