Canon imagePROGRAF iPF815 Service Manual

Chapter 6
6-4
T-6-4
T-6-5
T-6-6
T-6-7
3 GND - GND
J1801
Pin Number Signal name IN/OUT Function
1 AFCONT OUT Normal/Power saving switch signal
2 VM_ENB OUT VM enable signal
3 VMGND - GND
4 VMGND - GND
5 VM IN Power supply(+32V)
6 VM IN Power supply(+32V)
7 GND - GND
8 GND - GND
9 GND - GND
10 RGV20(+5V) IN Power supply(+5V)
11 RGV20(+5V) IN Power supply(+5V)
12 RGV20(+5V) IN Power supply(+5V)
J2402
Pin Number Signal name IN/OUT Function
1 VM_26V OUT Power supply(+26V)
2 MISTFAN_L_ALARM OUT Mist fan(L) alarm signal
3 MISTFAN_L_PWM OUT Mist fan(L) duty control signal
4 GND - GND
J2501
Pin Number Signal name IN/OUT Function
1 PUMPM1_AM OUT Purge motor drive signal AM
2 PUMPM1_AP OUT Purge motor drive signal AP
3 GND - GND
4 PUMPR_ENCA IN Pump encoder output signal A
5 RGV31(SNS5V_FU) OUT Power supply(+5V)
6 PUMPR_ENCB IN Pump encoder output signal B
7 RGV8(SNS3V) OUT Power supply(+3.3V)
8 GND - GND
9 /CONTROL_CAM_R IN Pump cam sensor output signal
10 RGV8(SNS3V) OUT Power supply(+3.3V)
11 GND - GND
12 /LIFT_CAM IN Lift cam sensor output signal
13 RGV8(SNS3V) OUT Power supply(+3.3V)
14 GND - GND
15 /CR_HP IN Carriage HP sensor output signal
16 OUT_LIFTM_VM OUT Power supply
17 OUT_LIFTM0_A OUT Lift motor drive signal A
18 OUT_LIFTM2_AX_N0 OUT Lift motor drive signal AX
19 OUT_LIFTM1_B OUT Lift motor drive signal B
20 OUT_LIFTM3_BX_N1 OUT Lift motor drive signal BX
J2601
Pin Number Signal name IN/OUT Function
1 POWER_ON IN Power switch signal
2 GND - GND
3 RGV20(+5V) OUT Power supply(+5V)
4 BUZZER OUT Buzzer control signal
5 PDO OUT Panel IC control signal
6 +3.3V OUT Power supply(+3.3V)
7 PDI OUT Panel IC data signal
8 HDD_LED OUT HDD lamp control signal
9 /PRESET OUT Panel reset signal
10 GND - GND
J1202
Pin Number Signal name IN/OUT Function

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
