Canon imagePROGRAF iPF815 Service Manual

Chapter 6
6-6
T-6-12
T-6-13
T-6-14
T-6-15
T-6-16
7 GND - GND
8 OUT_INK_DETECT6 IN Ink detection sensor output signal 6
9 OUT_INK_DETECT7 IN Ink detection sensor output signal 7
10 OUT_INK_DETECT8 IN Ink detection sensor output signal 8
11 OUT_TANK_DAT11 IN/OUT Ink tank data signal 11
12 OUT_TANK_DAT10 IN/OUT Ink tank data signal 10
13 OUT_TANK_DAT9 IN/OUT Ink tank data signal 9
14 OUT_INK_DETECT9 IN Ink detection sensor output signal 9
15 OUT_INK_DETECT10 IN Ink detection sensor output signal 10
16 OUT_INK_DETECT11 IN Ink detection sensor output signal 11
J4002
Pin Number Signal name IN/OUT Function
1 GND - GND
2 YOBITOM_ENC_1A IN HP maintenance jet pump encoder output signal A
3 RGV7(SNS5V2) OUT Power supply(+5V)
4 YOBITOM_ENC_1B IN HP maintenance jet pump encoder output signal B
5 YOBITOKYUUINMM_AM OUT HP maintenance jet purge motor drive signal AM
6 N.C - N.C
7 N.C - N.C
8 YOBITOKYUUINMM_AP HP maintenance jet purge motor drive signal AP
J3152
Pin Number Signal name IN/OUT Function
1 RGV16(VM32V) OUT Power supply(+32V)
2 RGV16(VM32V) IN Upper cover lock switch output signal
J2702
Pin Number Signal name IN/OUT Function
1 RGN17(VM_26V) OUT Power supply(+26V)
2 DCOVER_R OUT Upper cover lock solenoid(R) drive signal
3 RGV8(SNS3V) OUT Power supply (+3.3V)
4 GND - GND
5 /CUTTERM_SNS_R IN Cutter HP sensor output signal
6 GND - GND
7 /FUTO_CLMP OUT Head management sensor clamp signal
8 /FUTO_ON OUT Head management sensor ON signal
9 RGV31(SNS5V_FU) OUT Power supply(+5V)
10 /FUTO_CMP IN Head management sensor ink detection signal
11 N.C - N.C
12 N.C - N.C
13 N.C - N.C
14 N.C - N.C
J3002
Pin Number Signal name IN/OUT Function
1 TH2_OUT IN Thermister output signal
2 GND - GND
3 RH2_OUT IN Temperature/humidity sensor output signal
4 RGV29(UMF5V) OUT Power supply(+5v)
J3801
Pin Number Signal name IN/OUT Function
1 RGV8(SNS3V) OUT Power supply(+3V)
2 GND - GND
3 /PICKUP_ATUKAIJO_SNS_1 IN Roll media pick-up cam sensor output signal
4 RGV7(SNS5V2) OUT Power supply(+5V)
5 /KYUUSHI_SNS_F IN Roll media detection sensor output signal
J3201
Pin Number Signal name IN/OUT Function

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
