Chapter 6
6-7
T-6-17
T-6-18
T-6-19
T-6-20
T-6-21
6 GND - GND
7 RGV7(SNS5V2) OUT Power supply(+5V)
8 /KYUUSHI_SNS_R1 Roll media pick-up roller paper detection sensor output signal
9 GND - GND
10 RGV7(SNS5V2) OUT Power supply(+5V)
11 /YOUSHIHABA_SNS Roll media width detection sensor output signal
12 GND - GND
J4003
Pin Number Signal name IN/OUT Function
1 OUT_ZENMENM_B OUT Roll media pick-up motor drive signal B
2 OUT_ZENMENM_A OUT Roll media pick-up motor drive signal A
3 OUT_ZENMENM_BB OUT Roll media pick-up motor drive signal BB
4 OUT_ZENMENM_AB OUT Roll media pick-up motor drive signal AB
J3901
Pin Number Signal name IN/OUT Function
1 RGN19(VM_26V_2) OUT Power supply(+26V)
2 PICKUP_CL_OUT OUT Roll media pick-up cam clutch drive signal
3 RGN19(VM_26V_2) OUT Power supply(+26V)
4 KYUUSHI_CL_OUT OUT Roll media pick-up roller clutch drive signal
5 RGN19(VM_26V_2) OUT Power supply(+26V)
6 FLAPPER_SOL_OUT OUT Flapper solenoid drive signal
7 RGN19(VM_26V_2) OUT Power supply(+26V)
8 PINCH_CL_OUT OUT Pinch roller pressure clutch drive signal
9 RGV8(SNS3V) OUT Power supply(+3V)
10 GND - GND
11 /PINCH_CLOSE_SNS IN Pinch roller pressure detection sensor output signal
12 RGV8(SNS3V) OUT Power supply(+3V)
13 GND - GND
14 /PINCH_OPEN_SNS IN Pinch roller release detection sensor output signal
15 N.C - N.C
J3902
Pin Number Signal name IN/OUT Function
1 OUT_LENIP_BB OUT Pinch roller pressure motor drive signal BB
2 OUT_LENIP_B OUT Roll media pick-up motor drive signal B
3 OUT_LENIP_AB OUT Roll media pick-up motor drive signal AB
4 OUT_LENIP_A OUT Roll media pick-up motor drive signal A
J3151
Pin Number Signal name IN/OUT Function
1 RGV16(VM32V) OUT Power supply(+32V)
2 RGV16(VM32V) IN Upper cover lock switch output signal
3 N.C - N.C
J4001
Pin Number Signal name IN/OUT Function
A1 GND - GND
A2 LF_FNCA IN Feed roller encoder output signal A
A3 RGV29(UMF5V) OUT Power supply(+5V)
A4 LF_FNCB IN Feed roller encoder output signal B
A5 SNS3V(RGV18) OUT Power supply(+3.3V)
A6 GND - GND
A7 /LF_HP IN Feed roller HP sensor output signal
A8 GND - GND
A9 SPOOL_ENCA - N.C
A10 RGV29(UMF5V) - N.C
J3801
Pin Number Signal name IN/OUT Function
