Chapter 6
6-8
T-6-22
T-6-23
T-6-24
A11 SPOOL_ENCB - N.C
A12 N.C - N.C
A13 N.C - N.C
A14 N.C - N.C
B1 RGV19(VM_26V_2) OUT Power supply(+26V)
B2 YOBITOKYUUIN_FAN_ALA
RM_2
BP maintenance jet suction fan alarm signal
B3 GND - GND
B4 RGV8(SNS3V) OUT Power supply(+3.3V)
B5 GND - GND
B6 /CUTTERM_SNS_L IN Cutter left position sensor output signal
B7 CUTTERM_AM OUT Cutter motor drive signal AM
B8 CUTTERM_AP OUT Cutter motor drive signal AP
B9 RGV17(VM26V) OUT Power supply(+26V)
B10 DCOVER_L OUT Upper cover lock solenoid (L) drive signal
B11 RGV17(VM26V) OUT Power supply(+26V)
B12 SPOOL_CL_1OUT OUT Roll media rewinding clutch drive signal
B13 RGV17(VM26V) OUT Power supply(+26V)
B14 SPOOL_CL_2_OUT OUT Roll media pick-up roller clutch drive signal
J3150
Pin Number Signal name IN/OUT Function
1 IN 3- IN Hole sensor input signal 3-
2 IN 3+ IN Hole sensor input signal 3+
3 IN 1+ IN Hole sensor input signal 1+
4 IN 2- IN Hole sensor input signal 2-
5 IN 1- IN Hole sensor input signal 1-
6 IN 2+ IN Hole sensor input signal 2+
7 VM_GND - GND
8 +5V OUT Power supply (+5V)
9 OUT B OUT Motor output signal B
10 OUT B OUT Motor output signal B
11 OUT A OUT Motor output signal A
12 OUT A OUT Motor output signal A
13 OUT C OUT Motor output signal C
14 OUT C OUT Motor output signal C
J2801
Pin Number Signal name IN/OUT Function
1 OUT_LFSP_A OUT Feed motor drive signal A
2 OUT_LFSP_VM OUT Power supply(+32V)
3 OUT_LFSP_AB OUT Feed motor drive signal AB
4 OUT_LFSP_BB OUT Feed motor drive signal BB
5 OUT_LFSP_VM OUT Power supply(+32V)
6 OUT_LFSP_B OUT Feed motor drive signal B
J4101
Pin Number Signal name IN/OUT Function
A1 /OP_DACCHAKU_R_IN IN Lower roll unit release detection switch (R) output signal
A2 /OP_DACCHAKU_L_IN IN Lower roll unit release detection switch (L) output signal
A3 OP_KYUUSHI_UNIT - GND
A4 OP_FLAPPER_SOL OUT Lower flapper solenoid drive signal
A5 OP_PICKUP_CL OUT Lower roll media pick-up cam clutch drive signal
A6 OP_KYUUSHI_CL OUT Lower roll media pick-up roller clutch drive signal
A7 GND - GND
A8 GND - GND
A9 RGV19(VM_26V_2) OUT Power supply(+26V)
A10 RGV19(VM_26V_2) OUT Power supply(+26V)
A11 GND - GND
A12 RGV29(UMF5V) OUT Power supply(+26V)
A13 OP_SPOOL_ENCA_IN - N.C
J4001
Pin Number Signal name IN/OUT Function
