Canon imagePROGRAF iPF815 Service Manual

Chapter 6
6-13
T-6-30
15 PWLED2_ON IN Multi sensor LED2 drive control
16 H1-DATA_LICC2 IN Head(L) analogue switch data signal
17 H1-DLD_LICC2 IN Head(L) analogue switch latch signal
18 H1-DASLK_LICC2 IN Head(L) analogue switch clock signal
19 VH_DIS IN VH selection single
20 GND - GND
21 H1-E-DATA-9-EV_B IN Even head(L) data signal 9(E)
22 GND - GND
23 /H1-E-HE-9_B IN Head(L) heat enable signal 9(E)
24 GND - GND
25 H1-F-DATA-10-EV_B IN Even head(L) data signal 10(F)
26 GND - GND
27 H1-F-DATA-11-EV_B IN Even head(L) data signal 11(F)
28 GND - GND
29 /H1-F-HE-11_B IN Head(L) heat enable signal 11(F)
30 GND - GND
31 H1-F-DATA-11-OD_B IN Odd head(L) data signal 11(F)
32 GND - GND
33 /H1-F-HE-10_B IN Head(L) heat enable signal 10(F)
34 GND - GND
35 H1-E-DATA-9-OD_B IN Odd head(L) data signal 9(E)
36 GND - GND
37 H1-F-DATA-10-OD_B IN Odd head(L) data signal 10(F)
38 GND - GND
39 H1-E-DATA-8-OD_B IN Odd head(L) data signal 8(E)
40 GND - GND
41 /H1-E-HE-8_B IN Head(L) heat enable signal 8(E)
42 GND - GND
43 H1-D-DATA-7-OD_B IN Odd head(L) data signal 7(D)
44 GND - GND
45 H-DASH_LICC2 IN Head analogue switch A/D trigger signal
46 /OUT_ENB IN Head data enable signal
47 /CRCOVER OUT Printhead fixer lever sensor output signal
48 ENCODER_A OUT Linear encoder output signal A
49 ENCODER_B OUT Linear encoder output signal B
50 FFC OUT FFC disconnection detection signal
J202
Pin Number Signal name IN/OUT Function
1 /H1-B-HE-2_B IN Head(L) heat enable signal 2(B)
2 GND - GND
3 H1-A-DATA-1-OD_B IN Odd head(L) data signal 1(A)
4 GND - GND
5 H1-A-DATA-0-OD_B IN Odd head(L) data signal 0(A)
6 GND - GND
7 /H1-A-HE-0_B IN Head(L) heat enable signal 0(A)
8 GND - GND
9 H1-A-DATA-0-EV_B IN Even head(L) data signal 0(A)
10 GND - GND
11 /H1-A-HE-1_B IN Head(L) heat enable signal 1(A)
12 GND - GND
13 H1-A-DATA-1-EV_B IN Even head(L) data signal 1(A)
14 GND - GND
15 H1-B-DATA-2-EV_B IN Even head(L) data signal 2(B)
16 GND - GND
17 H1-B-DATA-3-EV_B IN Even head(L) data signal 3(B)
18 GND - GND
19 H1-C-DATA-4-EV_B IN Even head(L) data signal 4(C)
20 GND - GND
21 /H1-B-HE-3_B IN Head(L) heat enable signal 3(B)
22 GND - GND
23 H1-C-DATA-5-EV_B IN Even head(L) data signal 5(C)
24 GND - GND
25 /H1_LT_B IN Head(L) latch signal
J201
Pin Number Signal name IN/OUT Function

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
