Canon imagePROGRAF iPF815 Service Manual

Chapter 6
6-14
T-6-31
T-6-32
T-6-33
26 GND - GND
27 LV_H1_CLKP IN Head(L) clock signal P
28 LV_H1_CLKN IN Head(L) clock signal N
29 GND - GND
30 H1-DSOUT1 OUT Head(L) temperature output signal 1
31 H1-DSOUT2 OUT Head(L) temperature output signal 2
32 GND - GND
33 H1-C-DATA-5-OD_B IN Odd head(L) data signal 5(C)
34 GND - GND
35 /H1-C-HE-5_B IN Head(L) heat enable signal 5(C)
36 GND - GND
37 /H1-D-HE-6_B IN Head(L) heat enable signal 6(D)
38 GND - GND
39 H1-D-DATA-6-OD_B IN Odd head(L) data signal 6(D)
40 GND - GND
41 H1-D-DATA-6-EV_B IN Even head(L) data signal 6(D)
42 GND - GND
43 H1-D-DATA-7-EV_B IN Even head(L) data signal 7(D)
44 GND - GND
45 /H1-D-HE-7_B IN Head(L) heat enable signal 7(D)
46 GND - GND
47 H1-E-DATA-8-EV_B IN Even head(L) data signal 8(E)
48 GND - GND
49 IO_ASIC_SCL IN/OUT Head ROM control signal(clock)
50 IO_ASIC_SDA IN/OUT Head ROM control signal(data)
J205
Pin Number Signal name IN/OUT Function
1 ENCODER_B IN Linear encoder output signal B
2 GND - GND
3 ENCODER_A IN Linear encoder output signal A
4 SNS_5V OUT Power supply(+5V)
J206
Pin Number Signal name IN/OUT Function
1 SNS_5V OUT Power supply(+5V)
2 GND - GND
3 /CRCOVER IN Printhead fixer lever sensor output signal
J204
Pin Number Signal name IN/OUT Function
1 GND - GND
2 SNS5V OUT Power supply(+5V)
3 GND - GND
4 MLT_SENS_2IN IN Multi sensor signal 2
5 GND - GND
6 MLT_SENS_1IN IN Multi sensor signal 1
7 GND - GND
8 H1-C-DATA-4-OD OUT Odd head(L) data signal 4(C)
9 GND - GND
10 /H1-C-HE-4 OUT Head(L) heat enable signal 4(C)
11 GND - GND
12 H1-B-DATA-3-OD OUT Odd head(L) data signal 3(B)
13 GND - GND
14 H1-B-DATA-2-OD OUT Odd head(L) data signal 2(B)
15 GND - GND
16 /H1-B-HE-2 OUT Head(L) heat enable signal 2(B)
17 GND - GND
18 H1-A-DATA-1-OD OUT Odd head(L) data signal 1(A)
19 GND - GND
20 H1-A-DATA-0-OD OUT Odd head(L) data signal 0(A)
J202
Pin Number Signal name IN/OUT Function

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
