Canon imagePROGRAF iPF815 Service Manual

Chapter 8
8-10
2409 Paper position is not
suitable for
borderless printing.
Check paper position.
Print to normal printing.
Stop printing.
Invalid paper loading position (suspended
job/ borderless printing)
All of the following conditions were met.
-Borderless printing data has been
received.
-Roll paper whose paper loading position is
not suitable for borderless printing has
been loaded.
-The right or left edge of roll paper is more
than 1mm off the prescribed position of the
pre-ejection opening.
Reload/ replace the roll paper.
Check roll paper.
1) Select "Normal printing. (No
borderless printing)" and enforce
printing.
Borderless print setting is ignored.
Print with default margin.
Default margin depends on selected
feeding trays and media type.
2) Select "Stop printing" or press "stop
button"to stop printing.
3) Select "replace printing" or release
releasing lever.
240A Borderless printing is
not possible. Check
supported paper.
Check paper position.
Print to normal printing.
Stop printing.
Borderless printing is not possible
(suspended job/ unsupported size). All of
the following conditions are met.
-Borderless printing data has been
received.
-Roll paper not supporting borderless
printing has been loaded.
2500
to
250C
Ink tank is empty.
Press OK and
replace ink tank.
No Ink Left
(lower arrow)
Ink tank empty (continued use not allowed)
The ink tank has run out of ink. (The
reserved volume of ink is put to use after
the remaining ink falls below the pin check
level.)
(In the small LCD, the lower arrow points
to the color in question.)
The last 2 digits signify applicable colors.
00:Bk, 01:Y, 02:M, 03:C, 04:PM, 05:PC,
06:MBk1,
07:MBk2, 08:GY, 09:PGY, 0A:R, 0B:B,
0C:G
1. Replace the tank.
2. If the problem persists after the tank
has been replaced, the remaining ink
detection system is at fault (replace the
supply unit or check the bundled
wires).
No ink left.
Replace ink tank.
2510
to
251C
Ink level is
unknown.
Check ink level.
Press Online to start
printing.
Online Key
Press To Print
Ink Lvl Unknown
Press Online
Remaining ink level unknown (continued
use allowed)
The level of ink remaining in the tank is
detected when the tank cover is closed.
Consumption has exceeded the original ink
capacity (mismatch detected).
Refill ink may have been used.
(In the small LCD, the lower arrow points
to the color in question.)
The last 2 digits signify applicable colors.
10:Bk, 11:Y, 12:M, 13:C, 14:PM, 15:PC,
16:MBk1,
17:MBk2, 18:GY, 19:PGY, 1A:R, 1B:B,
1C:G
Replace the ink tank.
2520
to
252C
No ink tank
loaded.
Press OK and
check ink tank.
Ink Tank
Check XX
No Ink Tank
Check Ink Tank
Ink tank not installed (continued use not
allowed)
On a model that is furnished with a
subtank, this error is indicated if the
subtank has run out of ink and the state of
an ink tank not being installed is detected.
The last 2 digits signify applicable colors.
20:Bk, 21:Y, 22:M, 23:C, 24:PM, 25:PC,
26:MBk1,
27:MBk2, 28:GY, 29:PGY, 2A:R, 2B:B,
2C:G
1. Remove and then reinstall the tank.
2. Replace the tank.
3. Failure of remaining ink detection
system.
(Replace the supply unit /check the
bundled wires.)
No ink tank
loaded.
Check ink tank.
2540
to
254C
Ink tank error.
Press OK and
replace ink tank.
Ink Tank
Replace BK
Ink Tank Error
Repl. Ink Tank
Ink tank ID error
The type of ink tank is wrong.
The last 2 digits signify applicable colors.
40:Bk, 41:Y, 42:M, 43:C, 44:PM, 45:PC,
46:MBk1,
47:MBk2, 48:GY, 49:PGY, 4A:R, 4B:B,
4C:G
1. Replace the tank.
2. Failure of remaining ink detection
system.
(Replace the supply unit /check the
bundled wires.)
Wrong ink tank.
Replace ink tank.
Wrong ink tank.
Press OK and
replace ink tank.
2560
to
256C
Ink tank error.
Press OK and
replace ink tank.
Ink Tank
Replace BK
Ink Tank Error
Repl. Ink Tank
Ink tank EEPROM error
There is an error in tank EEPROM.
The last 2 digits signify applicable colors.
60:Bk, 61:Y, 62:M, 63:C, 64:PM, 65:PC,
66:MBk1, 67:MBk2, 68:GY, 69:PGY,
6A:R, 6B:B, 6C:G
1. Replace the tank.
2. Failure of remaining ink detection
system.
(Replace the supply unit /check the
bundled wires.)
Code
(last 4 digits)
Panel display
(Large LCD)
Panel display
(Small LCD)
Explanation/Detection sequence Remedial Action

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
