Canon imagePROGRAF iPF815 Service Manual

Chapter 1
1-40
[Interface Setup]
T-1-23
[Maintenance]
T-1-24
Setting Item Description/Instructions
[EOP Timer] Specify the timeout period before cancellation of print jobs that
cannot be received by the printer.
[TCP/IP] [TCP/IP] Specify the TCP/IP protocol settings. To apply your changes,
choose Register Setting.
[IP Mode] Choose whether the printer IP address is configured
automatically or a static IP address is entered manually.
[Protocol] [DHCP] Specify the protocol used to configure the IP address
automatically.
[BOOTP]
[RARP]
[IP Setting] [IP Address] Specify the printer network information when using a static IP
address.
Enter the IP address assigned to the printer, as well as the
network subnet mask and default gateway.
[Subnet Mask]
[Default G/W]
[NetWare] [NetWare] Specify the NetWare protocol. To apply your changes, choose
Register Setting.
[Frame Type] Specify the frame type to use.
[Print Service] Choose the print service.
[AppleTalk] Specify whether to use the AppleTalk protocol. To apply your
changes, choose Register Setting.
[Ethernet Driver] [Auto Detect] Specify the communication method. To apply your changes,
choose Register Setting.
Choose On for automatic configuration of the LAN
communication protocol. Choose Off to use settings values of
Comm.Mode and Ethernet Type.
[Comm.Mode] Choose the LAN communication method.
[Ethernet Type] Choose the LAN transfer rate.
[Spanning Tree] Choose whether spanning-tree packets are supported over the
LAN.
[MAC Address] Displays the MAC address.
[Init. Settings] A confirmation message is displayed if you press the button.
Choose [OK] to restore the network settings to the default values.
Setting Item Description/Instructions
[Maint. cart.] When exchanging the maintenance cartridge, choose Yes and follow the instructions on the
screen.
[Replace P.head] Not displayed during a warning message that the remaining Maintenance Cartridge capacity is
low.
When replacing the Printhead, choose Yes and follow the instructions on the screen.
[Repl. S. Cleaner] When replacing the Shaft Cleaner, choose Yes and follow the instructions on the screen.
[Move Printer] When transferring the printer to another location, choose the level of transfer and follow the
instructions on the screen.

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
