Canon iP4500 - LF; Eject Correction

17
6 times Green (Power) Asia Supported
7 times Orange (Alarm) China Supported
8 times Green (Power) Taiwan Supported
9 times Orange (Alarm) LAM Supported
10 times Green (Power) Brazil Not released
11 times Orange (Alarm) Canada Supported
12 times or more Green (Power) Return to the menu selection Supported
Note: After setting the destination, confirm the model name and destination in service test print or
EEPROM information print.
<Ink absorber counter resetting>
Reset the ink absorber counter (to 0%) when the ink absorber is replaced, or when necessary after the
logic board is replaced.
1) In the service mode, press the Resume/Cancel button 4 times, then press the Power button. The
ink absorber counter value of the EEPROM is reset to 0%.
2) The flag for resetting of the ink absorber counter is set to ON, and the ink absorber counter value is
automatically printed from the selected paper source. ("D=000.0" is printed at the top left of the
paper.)
<Ink absorber counter setting>
Set the ink absorber counter value to a new EEPROM after the logic board is replaced in servicing.
1) Before replacement of the logic board, check the ink absorber counter value in EEPROM
information print.
2) In the service mode, press the Resume/Cancel button 13 times, then press the Power button to
enter the ink absorber counter setting mode.
3) In the ink absorber counter setting mode, press the Power button again to enter the main ink
absorber counter setting mode. (Since the procedure for setting the ink absorber counter is
common among all the models, this step is necessary to set the counter value for the main ink
absorber.)
4) The ink absorber counter value can be set in 10% increments by pressing the Resume/Cancel
button. Press the Resume/Cancel button the appropriate number of time(s) to select the value
which is closest to the actual ink absorber counter value.
Time(s) Ink absorber counter value to be set (%)
0 times 0%
1 time 10%
2 times 20%
3 times 30%
4 times 40%
5 times 50%
6 times 60%
7 times 70%
8 times 80%
9 times 90%
10 times or more
Not valid. Press the Power button to return to the ink absorber counter setting
mode.
