3-2. Service Call Error (by Cyclic Blinking in Orange (Alarm LED) and Green (Power LED), or Alarm
LED Lit in Orange)
Cycles of blinking in
orange and green
Error Corrective Action
2 times Carriage error [5100] - Carriage unit (QM3-2264)
- Timing slit strip film (QC1-6526)
- Logic board ass'y (QM3-2738)
*1
- Carriage motor (QK1-1500)
3 times Line feed error [6000] - Timing sensor unit (QM3-2464)
- Timing slit disk film (QC2-4598)
- Feed roller ass'y (QL2-1490)
- Logic board ass'y (QM3-2738)
*1
- Paper feed motor (QK1-3849)
4 times Purge cam sensor error [5C00] - Purge unit (QM3-0007)
- Logic board ass'y (QM3-2738)
*1
5 times Rear tray (cam) sensor error [5700] - Sheet feed unit (QM3-2723)
6 times Internal temperature error [5400] - Logic board ass'y (QM3-2738)
*1
- Carriage unit (QM3-2264)
7 times Ink absorber full [5B00/5B01] - Ink absorber kit (QY5-0190)
8 times Print head temperature rise error [5200] - Print head (QY6-0067)
- Logic board ass’y (QM3-2738)
*1
9 times EEPROM / NVRAM error [6800]
NVRAM time out error [6801]
- Logic board ass'y (QM3-2738)
*1
10 times VH monitor error [B200] - Logic board ass'y (QM3-2738)
*1
- Print head (QY6-0067)
11 times Carriage lift mechanism error [5110] - PR lift shaft ass'y (QL2-1450)
- Sheet feed unit (QM3-2723)
- Logic board ass'y (QM3-2738)
*1
- Carriage lift sensor unit (QM3-1273)
12 times AP position error [6A00]
PG position error [5C10]
- Sheet feed unit (QM3-2723)
- Logic board ass'y (QM3-2738)
*1
- Purge unit (QM2-0007)
13 times Paper feed position error [6B00] - Sheet feed unit (QM3-2723)
- Logic board ass'y (QM3-2738)
*1
14 times Paper feed cam sensor error [6B10] - Sheet feed unit (QM3-2723)
- Logic board ass'y (QM3-2738)
*1
15 times USB Host VBUS overcurrent [9000] - Logic board ass'y (QM3-2738)
*1
16 times Pump roller sensor error [5C20] - Logic board ass'y (QM3-2738)
*1
- Purge unit (QM3-0007)
17 times Paper eject encoder error [6010] - Timing sensor unit (QM3-2464)
- Timing slit disk eject film (QC2-4599)
- Logic board ass'y (QM3-2738)
*1
- Paper feed motor (QK1-3849)
- Platen unit (QM3-2725)
19 times Ink tank position sensor error [6502] - Platen unit (QM3-0001)
- Logic board ass'y (QM3-2738)
*1
Power LED turned
off, and Alarm LED lit
ROM / RAM error - Logic board ass'y (QM3-2738)
*1
*1: Before replacement of the logic board ass'y, check the ink absorber counter value (by service test print or EEPROM
information print). If the counter value is 7% or more, also replace the Ink absorber kit (QY5-0190) when replacing
the logic board ass'y.
