53
NUMERICAL INDEX
PART NUMBER
FIGURE
&
KEY No.
DESCRIPTION
QA4-1117-000 1- 3 TRAY, CD SUB
QC1-6201-000 7- 2 SPRING, LEAF
QC1-6202-000 7- 11 SPRING, COIL
QC1-6212-000 10- 10 GEAR, IDLER CARRIAGE LIFT
QC1-6225-000 10- 21 GEAR, EJECT
QC1-6230-000 10- 19 BELT, PAPER FEED
QC1-6232-000 10- 3 SPRING, TENSION
QC1-6526-000 7- 1 FILM, TIMING SLIT STRIP
QC1-6573-000 3- 10 DAMPER, DOOR
QC1-6619-000 8- 3 SPRING, TENSION
QC1-9023-000 3- 2 EMBLEM
QC1-9024-000 3- 2 EMBLEM
QC1-9937-000 10- 5 SPRING, TORSION
QC1-9939-000 10- 17 BUSHING
QC1-9941-000 10- 1 CAM, SWING ARM LOCK
QC1-9987-000 3- 15 COVER, GAP
QC2-0030-000 9- 4 COVER, INK TUBE
QC2-0038-000 10- 12 GEAR, OUTPUT CARRIAGE LIFT
QC2-0039-000 10- 11 SPRING, TORSION
QC2-0040-000 10- 14 LEVER, SWING ARM LOCK
QC2-0052-000 10- 13 SPRING, TENSION
QC2-0080-000 7- 3 CLIP, SHAFT R
QC2-0083-000 7- 5 CLIP, SHAFT L
QC2-0085-000 9- 5 TUBE, INK JOINT
QC2-0089-000 9- 3 TUBE, INK
QC2-0414-000 7- 9 SHAFT, CARRIAGE
QC2-0424-000 3- 12 ARM, RELEASE
QC2-1873-000 10- 9 GEAR, INPUT CARRIAGE LIFT
QC2-1877-000 3- 14 COVER, INK MIST
QC2-1925-000 1- 2 COVER, CASSETTE
QC2-4418-000 3- 6 COVER, LEFT
QC2-4419-000 3- 7 MAIN CASE
QC2-4420-000 3- 8 COVER, I/F
QC2-4425-000 7- 7 CAM, CARRIAGE SHAFT L
QC2-4426-000 7- 4 CAM, CARRIAGE SHAFT R
QC2-4433-000 10- 8 CARRIAGE LIFT GEAR BASE UNIT
QC2-4880-000 10- 18 FILM, TIMING SLIT DISK
QC2-4881-000 8- 4 FILM, TIMING SLIT DISK EJECT
QC2-4888-000 8- 1 ABSORBER, INK
QC2-4900-000 3- 2 EMBLEM
QC2-5978-000 6- 4 COVER, PAPER FEED GUIDE
QC2-5980-000 3- 13 COVER, MAIN CASE
QH2-2716-000 1- 6 CORD, POWER
QH2-2719-000 1- 6 CORD, POWER
QK1-0776-000 1- 6 CORD, POWER
QK1-1500-000 7- 6 MOTOR, CARRIAGE
QK1-2017-000 1- 6 CORD, POWER
QK1-2830-000 9- 1 CABLE, PANEL
QK1-3048-000 1- 6 CORD, POWER
QK1-3691-000 2- 1 AC ADAPTER: 100V-240V 50/60HZ
QK1-3761-000 1- 6 CORD, POWER
QK1-3849-000 10- 16 MOTOR, PAPER FEED
QK1-3852-000 7- 12 CORE, RING
QL2-0938-000 7- 10 IDLER PULLEY ASS'Y
QL2-1449-000 1- 4 CDR TRAY ASS'Y
QL2-1450-000 10- 2 PR LIFT SHAFT ASS'Y
QL2-1490-000 10- 20 FEED ROLLER ASS'Y
QM2-3886-010 10- 6 PRESSURE ROLLER ASS'Y
QM2-3890-000 10- 4 PAPER GUIDE UNIT
PART NUMBER
FIGURE
&
KEY No.
DESCRIPTION
QM3-0007-010 9- 2 PURGE UNIT
QM3-1273-000 10- 7 CARRIAGE LIFT SENSOR UNIT
QM3-1274-000 10- 15 PE SENSOR UNIT
QM3-2189-000 3- 9 FRONT DOOR UNIT
QM3-2190-000 3- 3 ACCESS COVER UNIT
QM3-2191-000 3- 5 SIDE COVER R UNIT
QM3-2192-000 3- 4 FRONT COVER UNIT
QM3-2193-000 3- 1 PAPER SUPPORT UNIT
QM3-2264-000 7- 8 CARRIAGE UNIT
QM3-2464-000 10- 22 TIMING SENSOR UNIT
QM3-2718-000 4- 2 BOTTOM CASE UNIT
QM3-2720-000 1- 1 CASSETTE UNIT
QM3-2721-000 3- 11 INNER COVER UNIT
QM3-2723-000 6- 5 SHEET FEEDER UNIT
QM3-2725-000 8- 2 PLATEN UNIT
QM3-2738-000 5- 1 LOGIC BOARD ASS'Y
QM3-2740-000 6- 3 ENCORDER MULTI HARNESS ASS'Y
QM3-2746-000 6- 1 DC CONNECTOR ASS'Y
QM3-2749-000 6- 2 MOTOR MULTI HARNESS ASS'Y
QY5-0190-000 4- 1 ABSORBER KIT
QY6-0067-000 1- 5 PRINT HEAD
QY9-0057-000 T- 1 LUBE, FLOIL KG107A, OIL
WT3-5156-000 1- 6 CORD, POWER
WT3-5160-000 1- 6 CORD, POWER
XA9-1752-000 S- 2 SCREW, TAP, WASHER HEAD, M3X12
XA9-1754-000 S- 5 SCREW, BIND, M2.6X4(RED)
XB1-2200-405 S- 6 SCREW, M2X4
XB1-2300-405 S- 1 SCREW, MACH.BH, M3X4
XB2-4300-605 S- 3 SCREW, W/WASHER, M3X6
XB4-7300-805 S- 4 SCREW, TP, BH3X8
