33
LIST OF FIGURE3
FIGURE &
KEY No.
PART
NUMBER
RAN
K
QTY DESCRIPTION REMARKS
3- 1 QM3-2193-000 1 PAPER SUPPORT UNIT
2 QC1-9023-000 1 EMBLEM FOR JAPAN
2 QC1-9024-000 1 EMBLEM FOR OTHER REGIONS
2 QC2-4900-000 1 EMBLEM FOR FRANCE
3 QM3-2190-000 1 ACCESS COVER UNIT
4 QM3-2192-000 1 FRONT COVER UNIT
5 QM3-2191-000 1 SIDE COVER R UNIT
6 QC2-4418-000 1 COVER, LEFT
7 QC2-4419-000 1 MAIN CASE
8 QC2-4420-000 1 COVER, I/F
9 QM3-2189-000 1 FRONT DOOR UNIT
10 QC1-6573-000 1 DAMPER, DOOR
11 QM3-2721-000 1 INNER COVER UNIT
12 QC2-0424-000 2 ARM, RELEASE
13 QC2-5980-000 2 COVER, MAIN CASE
14 QC2-1877-000 1 COVER, INK MIST
15 QC1-9987-000 1 COVER, GAP W/O CDR PRINTING
