LIST OF FIGURE6
FIGURE &
KEY No.
PART
NUMBER
RAN
K
QTY DESCRIPTION REMARKS
6- 1 QM3-2746-000 1 DC CONNECTOR ASS'Y
2 QM3-2749-000 1 MOTOR MULTI HARNESS ASS'Y
3 QM3-2740-000 1
ENCORDER MULTI HARNESS
ASS'Y
4 QC2-5978-000 1 COVER, PAPER FEED GUIDE
5 QM3-2723-000 1 SHEET FEEDER UNIT
