Canon iP4500 - Page 42

41
LIST OF FIGURE7
FIGURE &
KEY No.
PART
NUMBER
RAN
K
QTY DESCRIPTION REMARKS
7- 1 QC1-6526-000 1 FILM, TIMING SLIT STRIP
2 QC1-6201-000 1 SPRING, LEAF
3 QC2-0080-000 1 CLIP, SHAFT R
4 QC2-4426-000 1 CAM, CARRIAGE SHAFT R
5 QC2-0083-000 1 CLIP, SHAFT L
6 QK1-1500-000 1 MOTOR, CARRIAGE
7 QC2-4425-000 1 CAM, CARRIAGE SHAFT L
8 QM3-2264-000 1 CARRIAGE UNIT
9 QC2-0414-000 N 1 SHAFT, CARRIAGE
10 QL2-0938-000 1 IDLER PULLEY ASS'Y
11 QC1-6202-000 1 SPRING, COIL
12 QK1-3852-000 2 CORE, RING
