47
LIST OF FIGURE10
FIGURE &
KEY No.
PART
NUMBER
RAN
K
QTY DESCRIPTION REMARKS
10- 1 QC1-9941-000
1 CAM, SWING ARM LOCK
2 QL2-1450-000
1 PR LIFT SHAFT ASS'Y
3 QC1-6232-000
2 SPRING, TENSION
4 QM2-3890-000
1 PAPER GUIDE UNIT
5 QC1-9937-000
4 SPRING, TORSION
6 QM2-3886-010
1 PRESSURE ROLLER ASS'Y
7 QM3-1273-000
1 CARRIAGE LIFT SENSOR UNIT
8 QC2-4433-000
1 CARRIAGE LIFT GEAR BASE UNIT
9 QC2-1873-000
1 GEAR, INPUT CARRIAGE LIFT
10 QC1-6212-000
1 GEAR, IDLER CARRIAGE LIFT
11 QC2-0039-000
1 SPRING, TORSION
12 QC2-0038-000
1 GEAR, OUTPUT CARRIAGE LIFT
13 QC2-0052-000
1 SPRING, TENSION
14 QC2-0040-000
1 LEVER, SWING ARM LOCK
15 QM3-1274-000
1 PE SENSOR UNIT
16 QK1-3849-000
1 MOTOR, PAPER FEED
17 QC1-9939-000
1 BUSHING
18 QC2-4880-000
1 FILM, TIMING SLIT DISK
19 QC1-6230-000
1 BELT, PAPER FEED
20 QL2-1490-000
1 FEED ROLLER ASS'Y
21 QC1-6225-000
1 GEAR, EJECT
22 QM3-2464-000
1 TIMING SENSOR UNIT
To Next Page
