Canon iPF600 series - 5.1 Periodic Replacement Parts; 5.2 Consumable Parts; 5.3 Periodic Maintenance

Chapter 5
5-1
5.1 Periodic Replacement Parts
5.1.1 Periodic Replacement Parts
0013-4084
T-5-1
5.2 Consumable Parts
5.2.1 Consumable Parts
0017-5584
T-5-2
- After supplies have been replaced, execute [INITIALIZE] > [PARTS COUNTER] > [PARTS xx] in service mode to initialize (clear) the parts counter information.
5.3 Periodic Maintenance
5.3.1 Periodic Maintenance
0017-5587
T-5-3
Level Periodic Replacement part
User None
Service
Personnel
None
Consumables Service Mode
Name Part number Q'ty
Life sheets/
A1
PARTS xx COUNTER x States (Error Code)
Service SUCTION FAN UNIT QM3-0701-000 1 15000 A1 A OK/W1/E146-4001
DUCT UNIT, PLATEN QM3-0801-000 1 15000 B1 B OK/W1/E146-4001
CARRIAGE UNIT QM3-0804-000 1 15000 D1 D OK/W1/W2
LEVER, L, INK TUBE QC2-0660-000 1 15000
LINK, LEVER, TUBE QC2-0661-000 2 15000
SPRING, TENSION QC2-1396-000 1 15000
PAD, OIL QC2-0664-000 2 15000
HOLDER, WIRE(MECH) QC2-0663-000 1 15000
TUBE GUIDE UNIT QM3-0704-000 1 15000
CLEANING UNIT, R, RAIL,
CARRIAGE
QM3-0543-000 1 15000 D1/D3
CLEANING UNIT, L, RAIL,
CARRIAGE
QM3-0542-000 1 15000 D1/D3
FLEXIBLE CABLE ASS'Y QM3-0806-000 1 15000 D2
ENCODER SENSOR UNIT QM2-3421-000 1 15000 D3
SCALE, LINEAR QC2-6052-000 1 15000
CAM, LIFTER QC2-0675-000 2 15000 D4
INK SUPPLY UNIT QM3-0568-040 1 15000 F1 F OK/W1/E141-4047
PURGE KIT QM3-0653-040 1 15000 H1 H OK/W1/E141-4046
SENSOR UNIT QM3-0529-000 1 15000 L1 L OK/W1/E194-404A
MOTOR, 26.4V, DC QK1-0447-000 1 15000 P1 P OK/W1/W2
ROLLER, PICK-UP QM3-0619-000 2 15000 Q1 Q OK/W1/W2
CAM, ROWEL QC2-1027-000 1 15000 R1 R OK/W1/W2
MIST FAN UNIT QM3-0799-000 1 15000 V1 V OK/W1/E146-4001
MIST FILTER UNIT QM3-0212-030 1 15000
User See "Product Overview> Features> Consumables"
Level Periodic maintenance
User Cleaning of ink mist and other substances(about once each month
Service personnel None
