2-5
FIGURE
& KEY
NO.
PARTS
NUMBER
R
A
N
K
Q'TY DESCRIPTION
SERIAL NUMBER/
REMARKS
S
V
C
Fig.02 NPN RF COVERS
1 QM3-5842-000 1 OPERATION PANEL UNIT
iPF765/760/755/
750:ENGLISH
1 QM3-5904-000 1 OPERATION PANEL UNIT
iPF765/760/755/
750:JAPANESE
1 QM4-8471-000 1 OPERATION PANEL UNIT iPF785/780:ENGLISH
1 QM4-8470-000 1 OPERATION PANEL UNIT iPF785/780:JAPANESE
1 QM4-8494-000 1 OPERATION PANEL UNIT iPF786/781
2 QC3-1695-000 1 KEY, SCROLL iPF765/760/755/750
3 QC3-1696-000 1 KEY, LOAD/CUT iPF765/760/755/750
4 QC3-1697-000 1 KEY, OK iPF765/760/755/750
5 QC3-1698-000 1 KEY, POWER iPF765/760/755/750
6 QC3-1690-000 1 COVER, TOP, LEFT iPF765/760/755/750
6 QD1-1245-000 1 COVER, TOP, LEFT iPF786/785/781/780
7 QM3-5885-000 1 LEFT COVER UNIT iPF765/760/755/750
7 QM4-8477-000 1 LEFT COVER UNIT iPF786/785/781/780
8 QM3-5886-000 1 RIGHT COVER UNIT iPF765/760/755/750
8 QM4-8478-000 1 RIGHT COVER UNIT iPF786/785/781/780
9 QC3-1742-000 1 CAP, BLANKING
10 QM3-5908-000 1 INK TANK COVER UNIT (L) iPF765/760/755/750
11 QM3-5909-000 1 INK TANK COVER UNIT (R) iPF750
11 QM3-5942-000 1 INK TANK COVER UNIT (R) iPF755
11 QM4-8157-000 1 INK TANK COVER UNIT (R) iPF760
11 QM4-8158-000 1 INK TANK COVER UNIT (R) iPF765
12 QM3-5878-000 1 FRONT COVER UNIT (L) iPF765/760/755/750
13 QM3-5879-000 1 FRONT COVER UNIT (R) iPF765/760/755/750
14 QM3-5882-000 1 UPPER COVER UNIT
15 QM3-5911-000 1 UPPER REAR COVER UNIT
16 QC3-1683-000 3 DAMPER
17 QM3-5947-000 1 FRONT COVER UNIT iPF765/760/755/750
17 QM4-8483-000 1 FRONT COVER UNIT iPF786/785/781/780
18 QC3-1829-000 3 COVER, CUTTER GUARD iPF765/760/755/750
18 QD1-0438-000 3 COVER, CUTTER GUARD iPF786/785/781/780
