Canon iPF780 Series - Page 282

2-6
19 QC3-1668-000 3 CAP, SCREW
20 QL2-3173-010 2 COVER, DELIVERY
21 QL2-3172-030 1 COVER, DELEVERY, RIGHT
22 QC3-1553-000 1 COVER, MAINTENANCE CARTRIDGE
23 XA9-1928-000 AR SCREW, TP, M3X8
24 QC3-1900-000 1 PAD
25 QC2-6633-000 1 LABEL
26 QD1-1235-000 1 FRONT COVER (L) iPF786/785/781/780
27 QD1-1239-000 1 INK TANK COVER TOP (L) iPF786/785/781/780
28 QD1-1240-000 2 INK TANK COVER iPF786/785/781/780
29 QD1-1253-000 2 PLATE, SUPPORT iPF786/785/781/780
30 QD1-1254-000 2 JOINT, INK TANK COVER iPF786/785/781/780
31 QD1-1234-000 1 FRONT COVER (R) iPF786/785/781/780
32 QD1-1238-000 1 INK TANK COVER TOP (R) iPF780
32 QD1-1281-000 1 INK TANK COVER TOP (R) iPF781
32 QD1-1278-000 1 INK TANK COVER TOP (R) iPF785
32 QD1-1282-000 1 INK TANK COVER TOP (R) iPF786
501 XB4-5300-807 12 SCREW, P, M3X8
FIGURE
& KEY
NO.
PARTS
NUMBER
R
A
N
K
Q'TY DESCRIPTION
SERIAL NUMBER/
REMARKS
S
V
C
