1-6
RM-Lite Viewer and VB-M700/600/40 Viewer Comparison
The RM-Lite viewer differs from the VB-M700/600/40 viewer built into the cameras in the following ways.
VB-M700/600/40 Viewer
RM-Lite Viewer
Note
PC, speaker and microphone sold separately.
Viewer type Live image display Audio
VB-M700/600/40 Viewer JPEG Receives audio from the camera (one-way communication)
RM-Lite Viewer JPEG/H.264 Transmits/receives audio (two-way communication)
Audio from the microphone connected to the camera can be listened to from the viewer speaker.
Microphone
(Sold separately)
Camera
JPEG
Audio
Speaker
Network
VB-M700/600/40
Viewer
Audio can be transmitted/received between the camera and viewer.
Microphone
(Sold separately)
Camera
JPEG/H.264
Audio
RM-Lite Viewer
Speaker
Network
Speaker
(Sold separately)
Microphone

Canon VB-M40 Specifications

General

Total megapixels	1.3 MP
Maximum resolution	1280 x 960 pixels
Supported video modes	-
Video formats supported	H.264
Supported graphics resolutions	160 x 120, 320 x 240, 1280 x 960, 640 x 480 (VGA)
Pan range	-170 - 170 °
White balance	Auto, Manual
Tilt angle range	-90 - 10 °
Minimum illumination	0.01 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Digital zoom	4 x
Optical zoom	20 x
Focal length range	4.7 - 94 mm
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	SD, SDHC
Form factor	Covert
Product color	Black
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired
Interface	RJ-45
Headphone outputs	1
Cabling technology	10/100Base-T(X)
AC input voltage	100-240 V
Power source type	PoE
AC input frequency	50 Hz
Storage temperature (T-T)	5 - 85 °C
Operating temperature (T-T)	-10 - 50 °C

Weight and Dimensions

Width	132 mm
Height	155 mm
Weight	1150 g
