Canon XA40 User Manual

Reference Tables
134
Reference Tables
Approximate recording times
The camcorder uses a variable bit rate (VBR) to encode video so the actual recording times will vary
depending on the subject. The following table shows the approximate recording times for a single
recording operation until the indicated SD card becomes full.
Charging, Recording and Playback Times
The charging times given in the following table are approximate and vary according to charging
conditions and initial charge of the battery pack.
Recording and playback times given in the following tables are approximate and vary according to
video configuration and charging, recording or playback conditions. The times are based on using the
LCD screen. The effective usage time of the battery pack may decrease when recording in cold
surroundings, when using the brighter screen settings, etc.
s
* Approximate times for recording with repeated operations such as start/stop, zooming, and power
on/off.
MP4 audio format Bit rate
SD card
8 GB 16 GB 32 GB 64 GB 128 GB
[ LPCM 16bit 4CH] 150 Mbps 5 min. 10 min. 25 min. 55 min. 110 min.
35 Mbps 25 min. 50 min. 110 min. 220 min. 445 min.
17 Mbps 45 min. 100 min. 205 min. 420 min. 845 min.
[ AAC 16bit 2CH] 150 Mbps 5 min. 10 min. 25 min. 55 min. 110 min.
35 Mbps 25 min. 55 min. 115 min. 240 min. 485 min.
17 Mbps 55 min. 120 min. 245 min. 495 min. 995 min.
8 Mbps 120 min. 255 min. 520 min. 1,055 min. 2,120 min.
Battery pack
BP-820 BP-828
Charging conditions
Using the camcorder 210 min. 300 min.
Using the CG-800 Battery Charger 190 min. 260 min.
Battery pack Resolution/Bit rate Recording (maximum) Recording (typical)* Playback
BP-820
3840x2160 (150 Mbps) 165 min. 90 min. 260 min.
1920x1080 (35 Mbps) 190 min. 105 min. 270 min.
1280x720 (8 Mbps) 165 min. 95 min. 280 min.
BP-828
3840x2160 (150 Mbps) 250 min. 140 min. 385 min.
1920x1080 (35 Mbps) 290 min. 160 min. 400 min.
1280x720 (8 Mbps) 260 min. 140 min. 415 min.

Canon XA40 Specifications

General

Filter size	58 mm
Digital zoom	- x
Optical zoom	20 x
Image stabilizer	Yes
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	1.8
Minimum aperture number	2.8
Focal length (35mm film equivalent)	29.3 - 601 mm
Sensor type	CMOS
Total megapixels	21.14 MP
Optical sensor size	1/2.3 \
Effective megapixels (movie)	8.29 MP
3D	No
Camcorder type	Handheld camcorder
Image processor	DIGIC DV 6
Minimum illumination	4.2 lx
Number of diaphragm blades	8
Focus adjustment	Auto/Manual
Closest focusing distance	0.01 m
Camera shutter speed	1/6 - 1/2000, 1/2 - 1/500 s
Built-in flash	-
Shoe mounting point type	Cold shoe
Cables included	AC
Number of batteries included	1 pc(s)
Battery type	BP-820
Battery capacity	1780 mAh
Battery life (max)	- h
Video recording time	2.9 h
Operating temperature (T-T)	-5 - 45 °C
Operating relative humidity (H-H)	0 - 85 %
Audio formats supported	AAC
Microphone connectivity	3.5 mm
Maximum image resolution	- pixels
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Video formats supported	MP4
Maximum video resolution	3840 x 2160 pixels
Bitrate at maximum video resolution	150 Mbit/s
Product color	Black
Viewfinder screen size	0.24 \
Display diagonal	3 \
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Internal storage capacity	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mini HDMI ports quantity	1
Component video (YPbPr/YCbCr) out	0

Weight and Dimensions

Depth	84 mm
Width	109 mm
Height	182 mm
Weight	730 g
