Canon XA40 User Manual

Setting the Time Code
64
Setting the Time Code
The camcorder generates a time code signal and records it with the recorded clips. The time code
signal can be output from the SDI OUT terminal (s only) and HDMI OUT terminal.
Depending on the frame rate used, you may be able to select between a drop frame an non-drop
frame time code signal (A 66). Though the time code display style is different for DF and NDF, in this
section the NDF display style is used for simplicity’s sake.
Selecting the Time Code Mode
1 Select [Time Code Mode].
> [3 " Recording Setup] > [Time Code Mode]
2 Select the desired option and then select [X].
• If you selected [ Regen.], you do not need to perform the following procedures to set the
time code running mode or the time code’s initial value.
Options
Setting the Time Code Running Mode
If you set the time code mode to [ Preset], you can select the time code running mode.
1 Select [Time Code Running Mode].
> [3 " Recording Setup] > [Time Code Running Mode]
2 Select the desired option and then select [X].
Options
Operating modes:
[ Preset]: The time code starts from an initial value you can select in advance. The default
initial time code is 00:00:00:00.
See the following procedures to select the time code running mode and set the
initial time code.
[ Regen.]: The camcorder will read the selected SD card and the time code will continue from
the last time code recorded on the card. The time code runs only while recording
so clips recorded consecutively on the same SD card will have continuous time
codes.
[ Rec Run]: The time code runs only while recording so clips recorded consecutively on the
same SD card will have continuous time codes.
[ Free Run]: The time code starts running the moment you confirm the selection and keeps
running regardless of the camcorder’s operation.

Canon XA40 Specifications

General

Filter size	58 mm
Digital zoom	- x
Optical zoom	20 x
Image stabilizer	Yes
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	1.8
Minimum aperture number	2.8
Focal length (35mm film equivalent)	29.3 - 601 mm
Sensor type	CMOS
Total megapixels	21.14 MP
Optical sensor size	1/2.3 \
Effective megapixels (movie)	8.29 MP
3D	No
Camcorder type	Handheld camcorder
Image processor	DIGIC DV 6
Minimum illumination	4.2 lx
Number of diaphragm blades	8
Focus adjustment	Auto/Manual
Closest focusing distance	0.01 m
Camera shutter speed	1/6 - 1/2000, 1/2 - 1/500 s
Built-in flash	-
Shoe mounting point type	Cold shoe
Cables included	AC
Number of batteries included	1 pc(s)
Battery type	BP-820
Battery capacity	1780 mAh
Battery life (max)	- h
Video recording time	2.9 h
Operating temperature (T-T)	-5 - 45 °C
Operating relative humidity (H-H)	0 - 85 %
Audio formats supported	AAC
Microphone connectivity	3.5 mm
Maximum image resolution	- pixels
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Video formats supported	MP4
Maximum video resolution	3840 x 2160 pixels
Bitrate at maximum video resolution	150 Mbit/s
Product color	Black
Viewfinder screen size	0.24 \
Display diagonal	3 \
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Internal storage capacity	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mini HDMI ports quantity	1
Component video (YPbPr/YCbCr) out	0

Weight and Dimensions

Depth	84 mm
Width	109 mm
Height	182 mm
Weight	730 g
