Pre-Recording
78
Pre-Recording
When pre-recording is activated, the camcorder starts recording continuously into a temporary
memory (approx. 3 seconds) so when you press the START/STOP button, the clip will contain also a
few seconds of video and audio recorded before you pressed the button.
1 Press the PRE REC button.
• Pre-recording is activated and z appears at the top of the
screen.
• Press the button again to turn off pre-recording.
2 Press the START/STOP button.
• The clip recorded on the card will include a few seconds of
video and audio recorded before the START/STOP button
was pressed.
NOTES
• The camcorder will not record the full 3 seconds prior to pressing the START/STOP button if the
button was pressed within 3 seconds of having turned on pre-recording or having finished the
previous recording.
• This function cannot be used together with slow & fast motion recording.
• Pre-recording will be deactivated in the following cases:
- When the power switch or camera mode switch is operated.
- When a menu is opened.
- When the shooting mode, white balance or look is changed.
- When the SD card compartment cover is opened or the SD card being recorded to becomes full.
• About the time code when pre-recording is activated:
- The time code of the clip will start a few seconds before the START/STOP button was pressed.
- If the time code mode was set to [ Regen.], or to [ Preset] with [ Rec Run] running
mode, the time code running mode will be changed automatically to [ Free Run] when pre-
recording is activated.
- When pre-recording is turned off, the time code running mode will return to its previous setting.
Operating modes:

Canon XA40 Specifications

General

Filter size	58 mm
Digital zoom	- x
Optical zoom	20 x
Image stabilizer	Yes
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	1.8
Minimum aperture number	2.8
Focal length (35mm film equivalent)	29.3 - 601 mm
Sensor type	CMOS
Total megapixels	21.14 MP
Optical sensor size	1/2.3 \
Effective megapixels (movie)	8.29 MP
3D	No
Camcorder type	Handheld camcorder
Image processor	DIGIC DV 6
Minimum illumination	4.2 lx
Number of diaphragm blades	8
Focus adjustment	Auto/Manual
Closest focusing distance	0.01 m
Camera shutter speed	1/6 - 1/2000, 1/2 - 1/500 s
Built-in flash	-
Shoe mounting point type	Cold shoe
Cables included	AC
Number of batteries included	1 pc(s)
Battery type	BP-820
Battery capacity	1780 mAh
Battery life (max)	- h
Video recording time	2.9 h
Operating temperature (T-T)	-5 - 45 °C
Operating relative humidity (H-H)	0 - 85 %
Audio formats supported	AAC
Microphone connectivity	3.5 mm
Maximum image resolution	- pixels
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Video formats supported	MP4
Maximum video resolution	3840 x 2160 pixels
Bitrate at maximum video resolution	150 Mbit/s
Product color	Black
Viewfinder screen size	0.24 \
Display diagonal	3 \
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Internal storage capacity	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mini HDMI ports quantity	1
Component video (YPbPr/YCbCr) out	0

Weight and Dimensions

Depth	84 mm
Width	109 mm
Height	182 mm
Weight	730 g
