Canon XA40 User Manual

Recording Audio
68
Recording Audio
The camcorder features 4-channel linear PCM or 2-channel AAC audio recording and playback. The
sampling frequency is 48 kHz and the audio sampling bit depth is 16 bit.
You can record audio using the built-in stereo microphone, commercially available external
microphone (INPUT 1/INPUT 2 terminals*, MIC terminal) or line input (INPUT 1/INPUT 2 terminals*).
Using the INPUT 1/INPUT 2 terminals, you can select the audio input independently for channel 1
(CH1) and channel 2 (CH2).
The audio signal will be output along with the video signal from the SDI OUT terminal (s only) and
HDMI OUT terminal. You can record this audio signal on an external recorder.
* Available only when the handle unit is attached to the camcorder.
Selecting the Audio Recording Format
You can set the audio recording format to AAC (2 channels, 16 bit) or linear PCM (4 channels, 16 bit).
When the resolution is set to 1280x720, the audio format is set to AAC and cannot be changed.
1 Select [¸ Audio Format].
> [3 ! Recording Setup] > [¸ Audio Format]
2 Select the desired option and then select [X].
Options
Operating modes:
[ AAC 16bit 2CH]:
The clip is recorded using 2-channel AAC. This format is more versatile and allows
the clip to be played back on various devices.
[ LPCM 16bit 4CH]:
The clip is recorded using 4-channel linear PCM. This format is uncompressed
and offers higher audio quality.

Canon XA40 Specifications

General

Filter size	58 mm
Digital zoom	- x
Optical zoom	20 x
Image stabilizer	Yes
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	1.8
Minimum aperture number	2.8
Focal length (35mm film equivalent)	29.3 - 601 mm
Sensor type	CMOS
Total megapixels	21.14 MP
Optical sensor size	1/2.3 \
Effective megapixels (movie)	8.29 MP
3D	No
Camcorder type	Handheld camcorder
Image processor	DIGIC DV 6
Minimum illumination	4.2 lx
Number of diaphragm blades	8
Focus adjustment	Auto/Manual
Closest focusing distance	0.01 m
Camera shutter speed	1/6 - 1/2000, 1/2 - 1/500 s
Built-in flash	-
Shoe mounting point type	Cold shoe
Cables included	AC
Number of batteries included	1 pc(s)
Battery type	BP-820
Battery capacity	1780 mAh
Battery life (max)	- h
Video recording time	2.9 h
Operating temperature (T-T)	-5 - 45 °C
Operating relative humidity (H-H)	0 - 85 %
Audio formats supported	AAC
Microphone connectivity	3.5 mm
Maximum image resolution	- pixels
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Video formats supported	MP4
Maximum video resolution	3840 x 2160 pixels
Bitrate at maximum video resolution	150 Mbit/s
Product color	Black
Viewfinder screen size	0.24 \
Display diagonal	3 \
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Internal storage capacity	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mini HDMI ports quantity	1
Component video (YPbPr/YCbCr) out	0

Weight and Dimensions

Depth	84 mm
Width	109 mm
Height	182 mm
Weight	730 g
