-19-
Operation 4
5. Turn steering wheel to turn.
4. Move drive lever gradually forward or
backward to move in the corresponding
direction.
3. Depress brake pedal to release brake pedal
lock.
1. M a k e c e r t a i n o f t h e s a f e t y o f y o u r
surroundings.
2. Move the throttle lever toward [HI (fast)]
position to increase engine speed.
5331M-0402-070E
Brake Pedal
Parking Brake Lever
5331M-0402-081E
Drive Lever
5331M-0402-090E
Steering Wheel
Speed can be adjusted continuously by the
position of drive lever.
NOTE
