Drive Belt
1. Remove upper rear cover.
2. Check V-belt tension. Inspect that the length
A of spring is within the range of 69 mm to
70mm. If it is out of this range, adjust spring
with adjust nut.
3. Visually inspect belt. Replace belt if it is
damaged. For replacement, contact your
CANYCOM representative.
4. Install upper rear cover back in place.
• Adjust belt tension properly. Inproperly tensioned belt may reduce performance
and its service life.
