5332M-0402-010E
Brake Pedal
Brake Lock Lever
1. Make certain brake pedal is depressed and
locked. If it is not, depress brake pedal and
pull lock lever to lock it.
• Safety feature: engine cannot be started
unless brake pedal is depressed.
5332M-0402-020E
Cutting Rotery
Clutch Lever
2. Make sure cutting rotary clutch lever is in
[OFF] position.
• Safety feature: engine cannot be started
unless cutting rotary clutch lever is in [OFF]
position.
5332M-0402-030E
Auxiliary
Transmission
Shift Lever
L
H
N
5332M-0402-040E
Drive Lever
Nutral Position
3. Make certain auxiliary transmission shift
lever is in [N (neutral)] position.
4. Make certain drive lever is in nutral position.
• Drive lever returns to neutral position when
brake pedal is fully depressed.
NOTE
NOTE
NOTE
