-29-
Operation 4
1. Gradually return drive pedal to slow down.
2. Take foot off drive pedal.
When Driving with Drive Pedal
• Drive pedal automatically returns to neutral
when released.
NOTE
5332M-0402-160E
Drive Pedal
5332M-0402-040E
Drive Lever
Nutral Position
1. Gradually return drive lever to nutral position
to slow down.
2. Release hand off drive lever.
When Driving with Drive Lever
5332M-0402-120E
Brake Pedal
3. Depress brake pedal to stop machine
completely.
• When brake pedal is depressed, drive lever
returns to neutral position.
5332M-0402-090E
Fuel Cock
Open
Close
4. Open engine hood and close fuel cock.
Close engine hood.
NOTE
