Connecting the different elements
The installation of this appliance and the connection to the electrical network should be made by an
electrician perfectly aware, and in respect of the normative regulations
Connecting the cooking zones
Each connector of the cooking zones, is located by a sticker with the classification from
5 to 8 corresponds to:
5: Heating zone 1100 W / Glass diameter 270mm
7: Heating zone 2300 W / Glass diameter 300mm
The touch control electronic is located in “C” on the connector
On the technical box, near the female connectors are written: 5-6-7-8-C.
Connect the touch control with the “C” of the technical box.
Connect the heating zones with the corresponding number on the technical box.
To connect easily, begin with the largest number of the heating zones.
Note: - It is strictly forbidden to lengthen or shorten the wire of the cooking zones.
- We do not take any responsibility in the case of not respecting the connections
indicated and the safety warnings.
